Product category:Electric circuit switches
Sensory Switch: Electric circuit switches is a kind of switch-type sensor (that is, non-contact switch). It has both the characteristics of a travel switch and a micro switch, and also has the sensing performance.
Principle: Inductive electric circuit switches; Model: LJ12A3-4-J/EZ; Line type: 3-wire type; Output type: NPN NO (normally open); Detection distance: 4mm; Current output: 400mA; Voltage: AC 90-250V; Thread diameter: 49mm/1.93"; Head diameter: 7.2mm/0.2"; Response frequency: 150Hz.
Excellent Performance: Electric circuit switches reliable action, stable performance, fast frequency response, long application life, strong anti-interference ability. LJ12A3-4-J/EZ is a component widely used for detecting, controlling and non-contact electric circuit switches.
Switch Appearance Type : Cylinder Type, Metal Shell;Output Type : NPN NC.Net Weight :100g; Color : Orange Tone, Silver.A control signal is sent out when the electric circuit switches is close to a target object. The orange LED indicates the sensor operating status.
Total Size : 62 x 10.5mm/ 2.4'' x 0.4' (L*Max.D);Cable Length : 1.2m/47.2;External Material : Plastic, Metal.
Multifunction: Can be used as limit, counting, positioning control and automatic protection in automatic control systems.
Widely Used: Widely used in machine tools, metallurgy, chemical industry, textile, printing, automatic control industry detection, control and non-contact switching industries, very suitable for papermaking, light industry limit station, positioning counting, overspeed test, security equipment, textile equipment, CNC machine tools, security inspection equipment, automated production lines, electronic machinery, etc.
